Cabinet Mounted Hot Water Electric Machines

B.A.R. Group - Cold Water Static Wall Mount

Technical Description – Premium Hot

  • HP Pump with 3 ceramic pistons on line
  • Electric Motor 230-400 Volt with 2 bearings and overload thermal protection
  • Vertical boiler with weldless double coil 3/8", bottom made of refractory cement
  • Delayed start of 6 second of burner spark
  • Independent burner
  • Flame control of the burner by photocell for maximum safety standards
  • Water tank with automatic float level
  • Machine stop in case of micro leakages
  • Device for suction of detergent in high pressure
  • Thermostat regulation temperature 30°-100° C
  • Temperature 30°-100° C
  • Nr. 3 pressure switches and 1 flow switch
  • Safety valve for pressure
  • Automatic stop of the machine if left idle for 30 minutes
  • Electric panel at 24 Volts with key lock
  • Delayed total stop adjustable 0-30 seconds
  • Stop of burner for lack of fuel
  • Fuel tank 40 litres
  • Pressure gauge for pressure adjustment
  • Double steel-plated, high pressure hose (10 metres)
  • Service lance with automatic gun
Model Static Hot 10/12 Static Hot 15/21 Static Hot 20/15 Static Hot 20/21 Big
Performance
Water Pressure - max. (Psi) 1550Psi 2175Psi 2900Psi 2900Psi
Water Flow Rate 12 l/min. 20 l/min. 15 l/min. 20 l/min.
Water Temperature 30° to 90° C 30° to 90° C 30° to 90° C 30° to 90° C
Steam up to 140° C up to 140° C up to 140° C up to 140° C
Electric Motor
Power Rating - kW 2.2 5.5 5.5 7.5
Voltage 240 Volt 415 Volt 415 Volt 415 Volt
Motor speed - rpm 1440 rpm 1440 rpm 1440 rpm 1440 rpm
Motor / Pump Coupling Hollow Shaft (double bearing) Internal Flexible Coupling
(Double Flange c/w elastic joint)		 Internal Flexible Coupling
(Double Flange c/w elastic joint)		 Internal Flexible Coupling
(Double Flange c/w elastic joint)
Pump
Pump - type Interpump Triplex Interpump Triplex Interpump Triplex Interpump Triplex
Pump - model W112 WS202 WS201 WS202
Pump - head Brass Brass Brass Brass
Water Break Tank √ √ √ √
Burner
Type C2 Double Coil (3/8" seamless) C3 Double Coil
Coil Mounting Vertical Vertical
Dimensions Height 184.5cm Width 86cm Depth 55cm
List Price * $7,399 $7,499 $7,799 $8,599

* Please note, prices EXCLUDE GST and freight
